10. Remove all of the screws holding the front of
the vat.
11. Remove the brackets located inside the splash
back.
12. Remove the upper rear cover.
Fry Vats:
Full Vats-
1. Remove ALL of the computer/controllers from
the machine.
2. Remove the burners and ignitors from the vat to
be removed.
3. Disconnect the drain valve switch wires.
4. Disconnect the return valve switch wires.
5. Disconnect the blower wires.
6. Remove the drain line from the left and right ends
of the drain valve tee.
7. Remove the 3 screws from the front of each unit.
8. Remove all of the nuts and washers holding the
splash deck in place.
9. Remove the front deck from the machine.
