TECHNICAL SPECIFICATIONSG
MODEL POWER VOLTAGE ABSORPTION (A) POWER (W) FLOW RATE (l/min)
CUBE MC 230 V / 50 Hz 4.2 900 70
CUBE 70 MC 110 V / 60 Hz 5.5 550 69
G1 PERMITTED USES
G2 USES NOT PERMITTED
G3 ABSORBED POWER
G4 HYDRAULIC PERFORMANCE
G5 CONTROL SYSTEM PERFORMANCE
G6 METERING ACCURACY
Transfer of diesel fuel with a viscosity from 2 to 5.35 cSt at 37.8°C and PM flash point > 55°C.
The transfer of fluids with different characteristics than those indicated above is not allowed.
In particular:
• Gasoline, solvents and inflammable liquids with PM < 55°C (danger of fire/explosion).
• Liquid food products (contamination of the same).
• Water (pump oxidation).
• Corrosive chemical products (pump corrosion).
• Liquids with viscosity > 20 cSt (motor overload).
The CUBE MC stations must be powered by a power line with the same RATED VOLTAGE /
FREQUENCY as that indicated on the IDENTIFICATION PLATE.
The maximum acceptable variations from the electrical parameters are:
- VOLTAGE +/- 5%
- FREQUENCY +/- 2%
The IDENTIFICATION PLATE shows maximum ABSORBED POWER (in Ampères), with
respect to which, the power protection appliances required by applicable standards (not
supplied with the station) must be sized.
The maximum absorbed power refers to intended-use operation - DISPENSING OF DIESEL
FUEL - with power supply within the above-mentioned limits.
When correctly installed and powered, and used for the purpose for which they were designed
- DISPENSING OF DIESEL FUEL - the CUBE MC stations perform as follows:
- Model CUBE MC: FLOW RATE MAX 70 litres/minute
The installed pumps ensure CONTINUOUS operation of the stations.
The performance of the MC control system is detailed in the M0103 manual supplied together
with the CUBE MC.
Thanks to the PULSER K600 METER and to the MC control system which ensures precise
CALIBRATION, the CUBE MC stations provide the following performance:
ACCURACY: +/- 0,5% (after calibration, for flow rates above 5 litres/minute).
EN
10
(Translated from Italian)
