SPECIAL MAINTENANCEN
MOTOR FUSES - 8A
POWER SUPPLY UNIT
FUSE
-100mA FOR VERSION
230V/50Hz
- 200mA FOR VERSION
110V/60Hz
In order to change the fuses inside the electronic board panel, we suggest proceeding as
follows:
- Interrupt power to the CUBE MC
- Remove the cover of the MC BOX panel
- Replace the burnt out fuses
- Close the panel again
- Restore power to the CUBE MC
