Pixsys ATR 171 User Manual

46 ATR171 - User manual
Table of configuration parameters
1
c.out
Command Output 27
2
s e n .1
Sensor 1 28
3
d. p.
Decimal Point 1 28
4
LOL.i
Lower Linear Input 1 28
5
u pL.i
Upper Limit Input 1 28
6
o . c a .1
Offset Calibration 1 28
7
G . c a .1
Gain Calibration 1 29
8
L t c .1
Latch-On 29
9
sen.2
Sensor 2 29
10
d . p. 2
Decimal Point 2 29
11
o. ca.2
Offset Calibration 2 29
12
G. ca .2
Gain Calibration 2 29
13
Lo .L. s .
Lower Limit Setpoint 30
14
u p.L. s .
Upper Limit Setpoint 2 30
15
c. pro .
Command Process 30
16
rem.s.
Remote Setpoint 30
17
act. t.
Command Action Type 30
18
c. Hy .
Command Hysteresis 30
19
c. re.
Command Rearmament 30
20
c. se.
Command State Error 31
21
c. Ld .
Command Led 31
22
c. d e.
Command Delay 31
23
c. s. p.
Command Setpoint Protection 31
24
tune
Tune 31
25
s.d.tu.
Setpoint Deviation Tune 31
26
p. b .
Proportional Band 31
27
t.i .
Integral Time 32
28
t.d.
Derivative Time 32
29
t. c.
Cycle Time 32
30
L.L. o . p.
Lower Limit Output Percentage 32
31
u.L.o.p.
Upper Limit Output Percentage 32
32
d eG r.
Degree 32
33
AL. 1
Alarm 1 32
34
a .1 . p r.
Alarm 1 Process 33
35
a .1 . s . o .
Alarm 1 State Output 33
36
a .1 . H y .
Alarm 1 Hysteresis 33
37
a1 . r e .
Alarm 1 Rearmament 33
38
a .1 . s . e .
Alarm 1 State Error 33
39
a.1.Ld.
Alarm 1 Led 33
40
a .1 . d e .
Alarm 1 Delay 33
41
a .1 . s . p .
Alarm 1 Setpoint Protection 34
