Page #27 background image
User manual - ATR171 27
11 Table of configuration parameters
The following table includes all parameters. Some of them will not appear on the
models which are not provided with relevant hardware data.
1
c.out
Command Output
Command output type selection
c. o1
Default
c.uaL
Command of open-loop valves
c.ss r
SSR command (voltage)
c.4. 20
Do not use this option for process retransmission
c.0.20
Do not use this option for process retransmission
c.0.10
Do not use this option for process retransmission
ATR17111ABC
Command Alarm 1
c. o1
Q1 SSR
c.uaL.
Q1 (open) - Q2 (close) -
c.ss r
SSR Q1
ATR17112ABC
Command Alarm 1 Alarm 2
c. o1
Q1 Q2 SSR
c.uaL.
Q1 (open) - Q2 (close) SSR -
c.ss r
SSR Q1 Q2
ATR17114ABC
Command Alarm 1 Alarm 2 Alarm 3
c. o1
Q1 Q2 Q3 Q4
c.uaL.
Q1 (open) - Q2 (close) Q1 Q4 -
ATR17123ABC
Command Alarm 1 Alarm 2 Alarm 3
c. o1
Q1 Q2 Q3 SSR
c.uaL.
Q1 (open) - Q2 (close) Q1 SSR -
c.ss r
SRR Q1 Q2 Q3
c.4. 20
4...20mA Q1 Q2 Q3
c.0.20
0...20mA Q1 Q2 Q3
c.0.10
0...10V Q1 Q2 Q3
