Pixsys ATR 171 User Manual

28 ATR171 - User manual
2
s e n .1
Sensor 1
Analogue input configuration / sensor selection (AI1).
di s .
Disabled (Default)
tc. k
Tc-K -260..1360 °C
tc. s
Tc-S -40..1760 °C
tc. r
Tc-R -40..1760 °C
tc. J
Tc-J -200..1200 °C
pt
PT100 -200..600 °C
p t 1
PT100 -200..140 °C
ni
NI100 -60..180 °C
ntc
NTC10K -40..125 °C
ptc
PTC1K -50..150 °C
p t5
PT500 -100..600 °C
p t 1k
PT1000 -100..600 °C
0. 10
0..10 Volt
0. 20
0..20 mA
4. 20
4..20 mA
0. 40
0..40 mVolt
p o t .1
Potentiometer max 6 Kohm (full scale)
po t.2
Potentiometer max 150 Kohm (full scale)
3
d. p.
Decimal Point 1
Select type of visualized decimal point for Analogue Input 1
0
Default
0.0
1 decimal
0.00
2 decimals
0.000
3 decimals
4
LOL.i
Lower Linear Input 1
AI1 lower range limit only for linear signals
-999..+9999 digit
3
(degrees if temperature), Default: 0
5
u pL.i
Upper Limit Input 1
AI1 upper limit setpoint
-999..+9999 digit
3
(degrees if temperature), Default: 1750
6
o . c a .1
Offset Calibration 1
Offset AI1 calibration. Value added/subtracted to visualized process value
(normally used to correct ambient temperature value)
-999..+1000 digit
3
for linear sensors and potentiometers.
-99.9..+100.0 tenths for temperature sensors, Default: 0.0.
3
The display of the decimal point depends on the setting of parameter
sen
. and
d. p. 1
or
sen.2
and
d . p. 2.
