Pixsys ATR 171 - Page 29

User manual - ATR171 29
7
G . c a .1
Gain Calibration 1
AI1 gain calibration. % value multiplied with displayed value to calibrate process value.
-99.9%..+100.0%, Default: 1000
Example: to correct a scale 0...1000°C which is showing 0...1010°C, enter -1.0 on
this parameter
8
L t c .1
Latch-On
Automatic setting of limits for linear input.
di s .
Disabled. Default
std.
Standard
u.0st.
Virtual Zero Stored (See par. 8.9)
u.0in.
Virtual Zero Initialized (See par. 8.9)
9
sen.2
Sensor 2
Analogue input 2 configuration / sensor selection AI2. Select dip-switches as
indicated on 5.1.c.
di s .
Disabled (Default)
tc. k
Tc-K -260..1360 °C
tc. s
Tc-S -40..1760 °C
tc. r
Tc-R -40..1760 °C
tc. J
Tc-J -200..1200 °C
pt
PT100 -200..600 °C
p t 1
PT100 -200..140 °C
ni
NI100 -60..180 °C
ntc
NTC10K -40..125 °C
ptc
PTC1K -50..150 °C
p t5
PT500 -100..600 °C
p t 1k
PT1000 -100..600 °C
10
d . p. 2
Decimal Point 2
Select decimal type visualized for analogue input 2.
0
Default
0.0
1 Decimal
11
o. ca.2
Offset Calibration 2
Offset AI1 calibration. Number added to visualized process value (normally
correcting environment temperature value) (only on ATR171-24ABC-T)
-99.9..+100.0 tenths of degree. Default: 0.0
12
G. ca .2
Gain Calibration 2
AI2 Gain calibration. % Value multiplied with displayed value to calibrate process value.
-99.9%..+100.0%, Default: 1000
ex: if input value is 0..1010°C and visualization is expected to be 0..1000°C set
parameter as -1.0
