Pixsys ATR 171 User Manual

Manuale d’uso - ATR171 89
Tabella delle configurazioni dei parametri
1
c.out
Command Output 69
2
s e n .1
Sensor 1 70
3
d. p.
Decimal Point 1 71
4
L.L.i .1
Lower Linear Input 1 71
5
u.Li.1
Upper Limit Input 1 71
6
o . c a .1
Offset Calibration 1 71
7
G . c a .1
Gain Calibration 1 71
8
L t c .1
Latch-On 71
9
sen.2
Sensor 2 72
10
d . p. 2
Decimal Point 2 72
11
o. ca.2
Offset Calibration 2 72
12
G. ca .2
Gain Calibration 2 72
13
Lo .L.S.
Lower Limit Setpoint 72
14
U p.L.S.
Upper Limit Setpoint 72
15
c. pro .
Command Process 73
16
rem.s.
Remote Setpoint 73
17
act. t.
Command Action Type 73
18
c. Hy .
Command Hysteresis 73
19
c. re.
Command Rearmament 73
20
c. se.
Command State Error 73
21
c. Ld .
Command Led 73
22
c. d e.
Command Delay 74
23
c. s. p.
Command Setpoint Protection 74
25
s.d.tu.
Setpoint Deviation Tune 74
26
p. b .
Proportional Band 74
27
t.i .
Integral Time 74
28
t.d.
Derivative Time 74
29
t. c.
Cycle Time 75
30
L.L. o . p.
Lower Limit Output Percentage 75
31
u.L.o.p.
Upper Limit Output Percentage 75
32
d eG r.
Degree 75
33
AL. 1
Alarm 1 75
34
a .1 . p r.
Alarm 1 Process 75
35
a .1 . s . o .
Alarm 1 State Output 76
36
a .1 . H y .
Alarm 1 Hysteresis 76
37
a1 . r e .
Alarm 1 Rearmament 76
38
a .1 . s . e .
Alarm 1 State Error 76
39
a.1.Ld.
Alarm 1 Led 76
40
a .1 . d e .
Alarm 1 Delay 76
41
a .1 . s . p .
Alarm 1 Setpoint Protection 77
42
aL. 2
Alarm 2 77
