User manual - ATR902 - 21
8
c. HY.
Command Hysteresis
Hysteresis in ON/OFF or dead band in P.I.D. for command output.
-99.9…+99.9 tenths of degree.> Default: 1.0.
9
P. b .
Proportional Band
Process inertia in degrees.
0.0 ON/OFF if also
t.i .
equal to 0. > Default.
0.1…999.9 tenths of degree.
10
t.i .
Integral Time
Process inertia in seconds.
0.0…999.9 seconds. Integral 0 disabled. > Default: 0.0.
11
t.d.
Derivative Time
Normally ¼ of integral time.
0.0…999.9 seconds. Derivative 0 disabled. > Default: 0.0.
12
t. c.
Cycle Time
Cycle time (for P.I.D. on contactor 10”/15”, for P.I.D. on SSR 1”)
1…300 seconds. > Default: 10.
13
c. s . e.
Command State Error
SContact status for command output in case of error.
o. c.
Open Contact > Default
c. c.
Closed Contact
14
ui . d .2
Visualization Display 2
Set visualization on display 2 during a cycle
e.st.s.
(End Step Setpoint) End temperature of operating step
r. s p u
(Real Setpoint) Updated according to the selected gradient
cy.nu.
(Cycle Number) Number of operating cycle. > Default
st.nu.
(Step Number) Number of operating step
ti m e
Time elaplsed from cycle start
15
de.st.
Delayed Start
Enables initial waiting for delayed start of cycle
di s .
(Disabled) Initial waiting disabled. > Default
en.
(Enabled) Initial waiting selectable by the user.
