Pixsys PL260 User Manual

24
Bit 10
If set to ON this bit enables mode “modem” for
serial port EXP1. This means that Timeout
between one character and the other
character in receiving mode is automatically
set to 40mS.
R/W
Bit 11
If set to ON this bit enables mode “modem” for
serial port COM2. This means that Timeout
between one character and the other
character in receiving mode is automatically
set to 40mS.
R/W
Bit 12
If set to 1, this bit disables internal clock
reading/writing, making faster program
execution.
R/W
Bit 13
If set to 1, this bit disables counters C[1..16]
and enables timers T[49..64], normally
disabled.
R/W
SM1
1001
Diagnostic Bit (faults/anomalies)
Bit 0
This bit is ON if the retaining data of the area
“special marker” are lost.
R/W
Bit 1
This bit is ON if the retaining data of the
“marker” area are lost.
R/W
Bit 2
This bit is ON if the retaining data of EEProm
area are lost.
R/W
Bit 3
This bit is ON if calibration data are lost. R/W
Bit 4
This bit is ON if the CPU has been reset or if
there is a watchdog intervention.
R/W
Bit 5
This bit is ON if there is stack overflow on the
ram reserved area.
R/W
Bit 6
This bit is ON if an error has occurred during
the calibration process.
R/W
Bit 7
This bit is ON if there is an error/fault of serial
EEprom.
R/W
Bit 8
This bit is ON if there is an error/fault of serial
clock.
R/W
Bit 9
This bit is ON if there is an error/fault of the 16
bit digital analogue converter.
R/W
Bit 10
This bit is ON if there is a stack overflow of
timed interrupts.
R/W
