32
Min. value for Analogue input AI1
Min. value for Analogue input AI2 linear
Min. value for Analogue input AI3 linear
Min. value for Analogue input AI4 linear
Min. value for Analogue input AI5 linear
Min. value for Analogue input
Max. value for Analogue input AI1 linear
Max. value for Analogue input AI2 linear
Max. value for Analogue input AI3 linear
Max. value for Analogue input AI4 linear
Max. value for Analogue in
Max. value for Analogue input AI6 linear
Select min. and max. numeric limits for the analogue
conversion of inputs AI configured as V/I (current and
tension). These words are modified using the
instruction RANGE(AIx,Min,Max). Default settings are
0 for min. value and 1000 for max. value.
R/W
Offset calibration Analogue input AI1
Offset calibration Analogue input AI2
Offset calibration Analogue input AI3
Offset calibration Analogue inp
Offset calibration Analogue input AI5
Offset calibration Analogue input AI6
Gain calibration Analogue input AI1
Gain calibration Analogue input AI2
Gain calibration Analogue input AI3
Gain calibration Analogue input AI4
Gain calibration Analogue input AI5
Gain calibration Analogue input AI6
These words define the calibration of conversion for
AI1..AI6. They are used to correct possible errors of
reading. The formule is as follows:
Value AIx = Value AIx + (Value AIx * Gain calibration
AIx) / 1000 Offset calibration AIx.
At starting all calibration values are set to zero.
R/W
