User manual - TCT101-1ABC - 13
8 Controller functions
8.1 Memory Card (optional)
Parameters and setpoint values can be duplicated from one
device to another using the Memory card.
There are two methods:
• With the device connected to the power supply
Insert the memory card when the controller is off.
On activation display 1 shows memo and display 2 show
---- (Only if the correct values are saved in the memory
card). By pressing the § key display 2 shows Lo ad, then
confirm using the ! key. The device loads the new data
and starts again.
• With the device not connected to power supply.
The memory card is equipped with an internal battery with
an autonomy of about 1000 operations. Insert the memory
card and press the programming button. When writing
the parameters, the led turns to red and on completing
the procedure it turns to green. It is possible to repeat the
procedure without any particular attention.
Updating Memory Card
To update the memory card values, follow the procedure
described for the first method, setting display 2 to ---- so as
not to load the parameters on controller
i
.
Enter configuration level and change at least one parameter.
Exit configuration. Changes are saved automatically.
i
If on activation the device does not display memo it means no data
have been saved on the memory card, but it is possible to update values.
