Pixsys TCT101-1ABC User Manual

6 - TCT101-1ABC - User manual
3 Technical data
3.1 General Features
Display
7 segments LED display: 4 digit 0,52 pollici, 4
digit 0,30 inches
Operating
temperature
Temperature: 0-40 °C -Humidity 35..95 uR%
Sealing
IP65 front panel (with gasket)
IP30 box, IP20 terminals blocks
Material Polycarbonate UL94V0 self-extinguishing
Weight Approx. 120 g
3.2 Hardware Features
Digital inputs
I1 - I2
Configurable via
software in mode:
NPN
PNP (max 28 VDC)
TTL.
Logical levels:
NPN:
H <4.7V
L > 5.7V
PNP:
H >5.7V
L <4.7V
TTL:
H >2.5V
L <2.0V
I3
Configurable via
software in mode:
PNP
TTL
POT (5..10 Kohm)
Logical levels:
PNP:
H >12.4V
L <10.2V
TTL:
H >2.5V
L <2.0V
Relay outputs
Q1 - Q2
Configurable
operation via
software.
Contacts:
5A - 230 VAC 1/2HP
for resistive load.
