Planar RPS - Color Balance

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 15
020-1332-00I
Color Balance
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
BACKLIGHT.
OFFSET
LCD Backlight
Offset
1424 =?+- PN#
0=ALL
-100..100 BACKLIGHT.OFFSET(3)=10
BACKLIGHT.OFFSET(3):10
Gets / sets panel backlight offset values for
brightness matching of LCDs.
No 4.0 Ye s No
COLOR.TEMP Color
Tem pera ture
1510 =? PN# or integer
NONE is all
0=3200K
1=5500K
2=6500K
3=8500K
4=9300K
5=NATIVE
6=CUSTOM
COLOR.TEMP?
COLOR.TEMP=8500K
Gets / sets wall color temperature. Note:
5500K and NATIVE is for LCD product only
and 9300K is for LED product only. To set a
custom color temperature for LED, it must
be set through the Planar Control Software
interface. A @NAK return indicates all
panels are not set the same.
No 4.0 Yes No
GRAY.BALANCE.
GAMMA
Color Balance -
Gray
1504 =? Panel ID
….and….
0=RED
1=GREEN
2=BLUE
255=ALL
1.8 .. 2.6 GRAY.BALANCE.GAMMA(1 red)?
GRAY.BALANCE.GAMMA(1
RED):2.200000
Gets / sets the gray balance value (gamma)
for the given LCD and color channel.
No 4.0 No No
RESET.BALANCE Color Balance
Reset
1506 ! RESET.BALANCE
RESET.BALANCE:@ACK
Resets the color balance of all LCDs back to
the last saved state
No 4.0 No No
WALL.RGB.GAIN LED RGB Gain
Values
611 =? 0=RED
1=GREEN
2=BLUE
255=ALL
0.000 THRU 100.000 WALL.RGB.GAIN(RED)?
WALL.RGB.GAIN(RED):100
Gets / sets the red, green and blue gain
settings for the wall. This command applies
to LED open pixel architectures only.
No 8.0 No No
WHITE.BALANCE White Balance
Setting
1525 =? Panel ID
….and….
0=RED
1=GREEN
2=BLUE
255=ALL
0.0 - 100.0 WHITE.BALANCE(1 RED)?
WHITE.BALANCE(1 RED):100.000000
Gets / sets the white balance value for the
given LCD and color channel
No 4.0 No No
