Planar RPS - Presets

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 28
020-1332-00I
Presets
1
Updated
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
PRESET.ACTIVE Active Preset 2010 ? Integer PRESET.ACTIVE?
PRESET.ACTIVE:2
Returns the active displayed preset slot
number. 0 (zero) indicates the current zone
layout has been modified since the last
preset was recalled, or that no preset has
ever been recalled.
No 4.0 Ye s No
PRESET.COUNT Saved Presets 2006 ? Integer PRESET.COUNT?
PRESET.COUNT:8
Returns the number of configured presets
in the system.
No 2.0 Yes Yes
PRESET.DELETE Delete Preset 2000 ! Integer 1-999 PRESET.DELETE(3)
PRESET.DELETE(3):@ACK
Deletes specified preset from the specified
preset slot.
No 2.0 Ye s Yes
PRESET.LIST Preset List 2008 ? Integer 1-PRESET.COUNT
…..and/or….
Integer 1-PRESET.COUNT
String PRESET.LIST?
PRESET.LIST:1 2 3 4
PRESET.LIST(3)?
PRESET.LIST:3
PRESET.LIST(2 3)?
PRESET.LIST:2 3
Returns a list of up to 64 preset slot
numbers that are currently utilized (has a
preset saved with that slot number). The
optional modifiers enable listing when
there are more than 64 saved presets. The
first modifier gives the 1-based index into
the list for the first returned value. If the
second modifier is omitted, only one value
is returned. When given, the second value
specifies the end index of the returned
values.
No 4.0 Yes No
PRESET.NAME Name Preset 2003 =? Integer 1-999 String PRESET.NAME(2)?
PRESET.NAME(2):"4K Video"
PRESET.NAME(2)=All 4K Sources
PRESET.NAME(2):"All 4K Sources"
Gets / sets the user assigned name of the
specified preset slot number.
No 2.0 Ye s Yes
PRESET.RECALL Load Preset 2001 ! Integer 1-999 PRESET.RECALL(4)
PRESET.RECALL(4):@ACK
Assigns the specified preset slot as the
active zone layout for the system.
No 2.0 No No
PRESET.SAVE Save Preset 2002 ! Integer 1-999 PRESET.SAVE(8)
PRESET.SAVE(8):@ACK
Saves the specified preset slot number
with the active zone layout. Overwrites any
existing saved preset with specified slot
number, or makes a new preset with
specified slot number if needed.
No 2.0 No No
PRESET.SLOT Preset Memory
Slot
2011 =? Integer 1-999 Integer 1-999 PRESET.SLOT(2)=1
PRESET.SLOT(2):1
Sets the memory slot location of a
specified valid preset.
Returns if a preset slot value is in use. See
PRESET.STATUS AND PRESET.LIST.
No 4.0 Yes No
PRESET.STATUS Preset Status 2009 ? Integer 1-999 0=EMPTY
1=FULL
PRESET.STATUS(1)?
PRESET.STATUS(1):FULL
Returns whether a specified preset slot
currently has information stored.
No 2.0
4.0
1
Yes Yes
