Planar RPS - Zone Setup and Control

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 34
020-1332-00I
Zone Setup and Control
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
ZONE.ADD Add Zone 2605 = Integer Integer ZONE.ADD(5)=0 0 1920 1080
ZONE.ADD(5):
Adds a zone number specified at in order: x
pixel dimension from zero x position of
wall, y pixel dimension from zero y position
of wall, x pixel width, y pixel height. Only
applicable to the active display/preset.
No 4.0 Yes No
ZONE.ASPECT Zone Aspect
Ratio
2610 =? Integer 0=FILL
1=CROP
2=16X9
3=4X3
4=NATIVE
5=AUTO
ZONE.ASPECT(5)?
ZONE.ASPECT(5):16X9
Gets / sets the how to scale/zoom of source
that does not fit the aspect ratio of a
specified zone. Only applicable to the
active display/preset.
No 4.0 Ye s No
ZONE.BACK Send Zone to
Back
2613 =? Integer ZONE.BACK?
ZONE.BACK:3
Gets / sets the zone at bottom of the zone
overlapping display area for the active
display.
No 4.0 Yes No
ZONE.CAPTURE.
PERCENT
Zone Capture in
%
2612 =? Integer 0.00 - 100.00 ZONE.CAPTURE.PERCENT(5)=25 25 75
75
ZONE.CAPTURE.PERCENT(5):25 25 75 75
Gets / sets for specified source in zone in
order: x offset percentage from zero x
position in zone, y offset percentage from
zero y position in zone, source x percent
capture area, source y percent capture
area. Numbers are based on percentage of
overall source dimensions. Only applicable
to the active display/preset.
No 4.0 Ye s No
ZONE.CAPTURE.
PIXEL
Zone Capture in
Pixels
2618 =? Integer Integer ZONE.CAPTURE.PIXEL(5)=480 270 1440
810
ZONE.CAPTURE.PIXEL(5):480 270 1440
810
Gets / sets for specified source in zone in
order: x offset pixel from zero x position in
zone, y offset pixel from zero y position in
zone, source x pixel capture area, source y
pixel capture area. Numbers are based on
overall source pixels. Only applicable to the
active display/preset.
No 4.0 Yes No
ZONE.COUNT Number of Zones 2609 ? Integer ZONE.COUNT?
ZONE.COUNT:8
Returns the number of zones configured in
the active display.
No 4.0 Ye s No
ZONE.DELETE Delete Zone 2600 ! Integer ZONE.DELETE(2)
ZONE.DELETE(2)@ACK
Deletes specified zone from active display. No 4.0 Yes No
ZONE.DUPLICATE Duplicate Zone 2619 = # Integer ZONE.DUPLICATE(4)=8
ZONE.DUPLICATE(4):8
ZONE.DUPLICATE(7)=0
ZONE.DUPLICATE(7):8
Creates duplicate zone with ID of operand
based on the zone ID in the modifier.
Operand of zero will create zone with the
next numerically unassigned zone ID.
No 9.0 Ye s Yes
