Planar RPS - Page 33

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 33
020-1332-00I
1
Updated
RUNTIME Device Total On
Time
1429 ? VC#
PS#
PN#
String RUNTIME(PS1)?
RUNTIME(PS1):"1562:24"
Returns the total time on for the specified
device in the format "HOURS:MINUTES". If
no device is specified runtime is returned
for the master component.
Yes 5. 1 Yes No
SYSTEM.STATE System State 2310 ? 0=STANDBY
1=POWERING.ON
2=ON
3=POWERING.DOWN
4=BACKLIGHT.OFF
5=FAULT
SYSTEM.STATE?
SYSTEM.STATE:STANDBY
Indicates the current state of the system.
-STANDBY: The system is in its lowest
power mode. Not all function are available
-POWERING.ON: The system is transitioning
from the STANDBY state to the ON state
-ON: The system is on with the displays on
-POWERING.DOWN: The system is
transitioning from the ON state to the
STANDBY state
-BACKLIGHT.OFF: The system is on and the
displays are off
-FAULT: A system failure has occurred
No 1.x Yes Yes
SYSTEM.VERSION Firmware Version 2302 ? String SYSTEM.VERSION?
SYSTEM.VERSION:"4.0.567"
Returns the software version of the system
based on the master component.
Yes 1. x
4.0
1
Yes Yes
TEMPERATURE
Device
Tem pera ture
1431 ? PN#
VC#
PS#
Float TEMPERATURE(VC1)?
TEMPERATURE(VC1):30.438000
Returns the temperature of the specified
device. If no modifier is provided, returns
the temp of the master component.
Yes 5.1 Yes No
UPTIME Device On Time 1430 ? PS#
VC#
String UPTIME(VC1)?
UPTIME="4:16"
Returns the total time on since last reboot
of the specified device in
"HOURS:MINUTES". If no modifier is
provided, returns the uptime of the master
component.
No 5.1
7.0
1
Yes No
VOLTAGE Input AC Voltage 1432 ? PS#.MODULE#
PN#
Float VOLTAGE(PS1.MODULE1)?
VOLTAGE(PS1.MODULE1):118.203354
Returns the voltage for the specified power
supply module.
Yes 5.1
6.0
1
Yes No
TIME.STRING System Time 1103 ? String TIME.STRING?
TIME.STRING:"2018-12-14 22:59:30"
Returns system current date and time in a
standard format.
No 5.1 Yes No
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
