Planar RPS - Status

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 30
020-1332-00I
Status
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
ALERT.COUNT System Alert
Count
2319 ? Integer ALERT.COUNT?
ALERT.COUNT:21
Returns the number of configurable
system alerts.
No 2.0
5.1
1
Yes Yes
BREAKER.OPEN Tripped Breaker
Monitor
1435 ? PS# BREAKER.OPEN(PS1)?
BREAKER.OPEN:NO NO
Returns if the breaker position is ON(NO) or
OFF(YES) in sequence from 1 to number of
outputs on the model RPS.
No 5.1 Yes No
CABINET.INPUT.
STATUS
Cabinet Input
Status
1535 ? Panel ID
….and….
Cabinet X position
….and….
Cabinet Y position
0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
…and…
0=NONE
1=HDMI1
2=HDMI2
…and…
0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
…and…
0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
CABINET.INPUT.STATUS(pn2 1 2)?
CABINET.INPUT.STATUS(PN2 1 2): YES
HDMI1 YES NO
Returns the following about a cabinet:
Connected (YES/NO), Active Input (HDMI1,
HDMI2), HDMI1 present (YES/NO), HDMI2
present (YES/NO).
No 5.1
7.0
1
Yes No
CONNECTION Panel Connection 1542 ? PN#
…or…
VC#.OUT#
VC#.OUT#
…or…
PN#.IN#
CONNECTION(PN2)?
CONNECTION(PN2):VC3.OUT6
CONNECTION(PN3)?
CONNECTION(PN3):VC2.OUT1
VC2.OUT2
CONNECTION(VC2.OUT1)?
CONNECTION(VC2.OUT1):PN3.IN1
Gets the output(s) of the VC that a panel is
connected to or the input of a panel that a
VC output is connected to. For 4k panels,
the first value returned is the primary (IN1)
and the second value is the secondary (IN2)
connection.
No 6.0
7.0
1
Yes No
CONNECTED Device
Connected
1426 ? PS#
VC#
PN#
PSW#
0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
CONNECTED(VC3)?
CONNECTED(VC3):NO
Gets connected status of the indicated
device. With no modifier, gets connected
status of the directly connected device.
Yes 4. 0
7.0
1
10.0
1
Yes No
FAN.STATUS VC Fan Status 1433 ? VC# 0=OK
1=FAULT
FAN .STATUS( VC1) ?
FAN .STATUS: OK
Returns the specified VC fan status. Yes 5.1 Yes No
FUSE.OPEN Auxiliary RPS
Fuse Status
1434 ? PS# 0=NO
1=YES
FUSE.OPEN(PS1)?
FUSE.OPEN:YES YES
Returns the fuse status for each fuse on the
specified device.
Yes 5. 1 Yes No
