RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 31
020-1332-00I
GENLOCK.
LOCKED
Genlock Status 1517 ? VC# or ALL 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
GENLOCK.LOCKED(VC1)?
GENLOCK.LOCKED(VC1):YES
Returns whether the equipment is locked
to a sync source.
No 2.1 Yes No
INFOFRAME HDR Data Header 305 ? VC#.IN#
VC#.OUT#
Hex String INFOFRAME(VC1.IN2)?
INFOFRAME(VC1.IN2):"87011A0D02004
88A08393421AA9B9619FC08133D4240
E80332000000000000"
Gets the HDR meta data for the specified
input or output of systems with HDR
enabled.
No 8.0 Yes No
INPUT.INFO Get Input
Information
300 ? VC#.IN#
….and optional….
0=BRIEF (DEFAULT)
1=ALL
String INPUT.INFO(VC1.IN4)?
INPUT.INFO(VC1.IN4):TRUE 1440 900 P
59.89
INPUT.INFO(VC1.IN4 BRIEF)?
INPUT.INFO(VC1.IN4 BRIEF):TRUE 1440
900 P 59.89
INPUT.INFO(VC1.IN4 ALL)?
INPUT.INFO(VC1.IN4 ALL):TRUE 1440
900 P 59.89 RGB 444 24 1904 934 55.934
106.499 SDR
Returns in order: input present, width,
height, P (progressive) / I (interlaced),
vertical refresh, colorspace, subsampling,
bits per pixel, H total, V total, H freq (kHz),
pixel clock (MHz), Dynamic Range.
Yes 4.0 Yes No
INPUT.INFO Get Input
Information
300 ? VC#.IN#
….and optional….
0=BRIEF (DEFAULT)
1=ALL
String INPUT.INFO(VC1.IN4)?
INPUT.INFO(VC1.IN4):TRUE 1440 900 P
59.89
INPUT.INFO(VC1.IN4 BRIEF)?
INPUT.INFO(VC1.IN4 BRIEF):TRUE 1440
900 P 59.89
INPUT.INFO(VC1.IN4 ALL)?
INPUT.INFO(VC1.IN4 ALL):TRUE 1440
900 P 59.89 RGB 444 24 1904 934 55.934
106.499
Returns in order: input present, width,
height, P (progressive)/ I (interlaced),
vertical refresh, colorspace, subsampling,
bits per pixel, H total, V total, H freq (kHz),
pixel clock (MHz).
Yes 4. 0 Yes No
INPUT.PRESENT Source
Connected
302 ? VC#.IN# 0=FALSE
1=TRUE
INPUT.PRESENT(VC3.IN4)?
INPUT.PRESENT(VC3.IN4):FALSE
Returns if a source is active on the specified
input.
Yes 4.0 Yes No
MESSAGE.COUNT System Message
Count
2324 ? Integer MESSAGE.COUNT?
MESSAGE.COUNT:10
Returns a count of the current system
messages.
Yes 5. 1 Yes Yes
PA NEL .P OWE R Panel On/Off 1538 =? PN# 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
PA NEL .P OW ER?
PA NEL .P OW ER: 0
Gets / sets the backlight to on or off of the
selected display
No 7.0 Yes No
PA NEL .R X.
LENGTH
Data Cable
Length
1541 ? PN# String PANEL.RX.LENGTH(PN3)?
PANEL.RX.LENGTH(PN3):"<20m"
Returns an estimate of the CAT cable from
the VC to the specified panel.
No 6.0 Yes No
PA NEL .S IGN AL .
QUALITY
Output Cable
Signal Quality
1536 ? PN# String PANEL.SIGNAL.QUALITY(PN2)?
PANEL.SIGNAL.QUALITY(PN2):"-22dB, -
22dB, -23dB, -22dB"
Returns panel signal quality as a string. No 5.1 No No
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
