Planar RPS - Configuration

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 16
020-1332-00I
Configuration
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
AUTO.LAYOUT Auto Wall Layout 608 ! PN# AUTO.LAYOUT
AUTO.LAYOUT@ACK
AUTO.LAYOUT(PN2)
AUTO.LAYOUT(PN2)@ACK
For LCD products, the command uses the
position sensors to auto layout the panels
within a system. No modifier used for LCD
products. When a modifier is used, the
effect will be on LED cabinets within the
range of the panel indicated by the
modifier.
No 7.0 Yes No
AUTO.ON Auto Power On 1407 =? 0=DISABLED
1=POWER_ON
2=PREVIOUS_STATE
AUTO.ON=POWER_ON
AUTO.ON:POWER_ON
Gets / sets if the system will turn on if the
AC power is applied.
No 1.x
2.0
1
Yes Yes
BACKLIGHT.
MAXIMUM
Maximum
Brightness
Setting
1417 =?+- 40-100 BACKLIGHT.MAXIMUM=50
BACKLIGHT.MAXIMUM:50
Gets / sets maximum wall brightness. No 4.0 Yes No
BACKLIGHT.
MODE
Auto Brightness 1402 =? 0=AUTO
1=MANUAL (default)
BACKLIGHT.MODE=MANUAL
BACKLIGHT.MODE:MANUAL
Gets / sets wall brightness adjustment
mode, where AUTO enables the system to
automatically change brightness based on
ambient sensor value.
No 4.0 Ye s No
CABINET.INPUT Active Cabinet
Input
1534 =? PN# 0=AUTO
1=HDMI1
2=HDMI2
CABINET.INPUT(PN2)=AUTO
CABINET.INPUT(PN2):AUTO
Gets / sets the active input setting on the
first cabinet of the specified panel.
Yes 5. 1 Ye s No
CUSTOM.COLOR Custom Color
Display
1314 =? PN#
0=ALL (default)
0-1023 CUSTOM.COLOR(PN4)=100 255 10
CUSTOM.COLOR(PN4):100 255 10
Gets / sets in order: Red, Green, Blue color
value. When set for a panel, also enables
PAT TERN(panel)=CUSTOM. When set for
ALL, this command ONLY sets the custom
color value and does not activate any
PAT TERN. PAT TERN command equal to
NONE required to remove.
No 4.0 No No
DEVICE.DELETE Delete External
Device
2700 ! PSW# DEVICE.DELETE(PSW1)
DEVICE.DELETE(PSW1)@ACK
Deletes the specified device from system. No 8.0 Yes Yes
DEVICE.GROUP External Device
Group
2704 =? PSW# String DEVICE.GROUP(PSW2)="LEFT WALL"
DEVICE.GROUP(PSW2):"LEFT WALL"
Gets / sets for specified device the group
affiliation associated. Quotes must be used
to set any group names that have spaces.
No 8.0 Ye s Yes
DEVICE.NAME External Device
Name
2703 =? PSW# String DEVICE.NAME(PSW4)="LEFT COLUMN"
DEVICE.NAME(PSW4):"LEFT COLUMN"
Gets / sets for specified device the unique
name associated. Quotes must be used to
set any names that have spaces.
No 8.0 Yes Yes
