RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 17
020-1332-00I
FIRMWARE.
UPDATE
Update Firmware 2200 =?! String FIRMWARE.UPDATE="usb:firmware.pkg"
FIRMWARE.UPDATE:"ackknowledged"
FIRMWARE.UPDATE?
FIRMWARE.UPDATE:"USB.FIRMWARE.
PKG" 0 1 "success" 1
No operator checks the attached USB drive
for latest default filename structure
firmware .pkg file in numeric order and
updates to latest.
= operator is used to assign specific file
name for update
? Operator will return status of update.
Data only valid before device reboot.
Only applies to the attached equipment.
Yes 1.x
2.1
1
7.0
1
Yes No
FIRMWARE.
VERSION
Get unit FW
version
2320 ? PS#
VC#
PN#
PSW#
String FIRMWARE.VERSION?
FIRMWARE.VERSION:4.0.569
Gets current firmware version of the
specified device. No modifier returns
system master firmware version.
Yes 4. 0
10.0
1
Yes No
GENLOCK.AUTO Auto Genlock 1518 =? 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
GENLOCK.AUTO?
GENLOCK.AUTO:ON
Gets / sets whether the equipment is set up
to automatically genlock to a source.
No 2.1 Ye s No
GENLOCK.
DISABLE
Disable Genlock 1519 =? 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
GENLOCK.DISABLE=0
GENLOCK.DISABLE:FALSE
Gets / sets whether the genlock feature is
disabled.
No 2.1 Yes No
GENLOCK.
REFERENCE
Genlock
Reference Source
1516 =? VC# 0=SYNC_IN
1=IN1
2=IN2
3=IN3
4=IN4
5=DP
6=INTERNAL
GENLOCK.REFERENCE=0
GENLOCK.REFERENCE:SYNC_IN
Gets / sets the sync reference source to be
used with the connected equipment. Note:
DP not an option for High Speed Link VCs..
No 2.1
10.0
1
Yes No
HDR.ENABLE Enable HDR 610 =?+- 0=DISABLE=OFF=FALSE
=AUTO
1=ENABLE=YES=TRUE=
HDR10
HDR.ENABLE?
HDR.ENABLE:ENABLE
Gets / sets the system capability to process
HDR source signals to the display.
No 8.0
9.0
1
Yes Yes
ID Component ID 1911 =? VC#
PS#
PN#
PSW#
String ID(VC3)=4
ID(VC3):4
Gets / sets the ID of the component
specified.
No 1.x
2.0
1
6.0
1
10.0
1
Yes No
IDENTIFY Identify Power
Supply ID
1910 ! String String IDENTIFY(PS2)
IDENTIFY(PS2):@ACK
Sends command to system for the system
master control LED on the specified remote
power supply to blink 3 times rapidly and
cycle this behavior several times.
No 2.0 Yes No
INPUT.
BRIGHTNESS
Input Brightness 200 =? VC#.IN# 0-100 INPUT.BRIGHTNESS(VC1.IN4)=56
INPUT.BRIGHTNESS(VC1.IN4):56
Gets / sets the input brightness value for
the specified input.
No 6.0 Ye s No
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
