RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 14
020-1332-00I
Basic Control
1
Updated
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
BACKLIGHT.
INTENSITY
Brightness
Intensity
1400 =?+- 0-100 BACKLIGHT.INTENSITY?
BACKLIGHT.INTENSITY:80
Gets / sets the intensity of the display. No 2.0 No No
POWER.
COMMAND
External Device
Power
2702 = PSW# or
PSW,ALL
PSW,GROUP
PSW,NAME
PS#
0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
2=CYCLE
POWER.COMMAND(PSW3)=OFF
POWER.COMMAND(PSW3):"OFF"
POWER.COMMAND(PSW,NAME)=CYCLE
"LEFT COLUMN" 5
POWER.COMMAND(PSW,NAME):
"CYCLE" "LEFT COLUMN" "5"
Sets the main power output of the
specified device. Second modifier may be
used to change bulk states of devices by
predefined tags.
Operand CYCLE may be followed by an
integer that denotes a delay time in
seconds for the specified device to change
from the opposite power state back to its
current power state. If no number is
entered, 10 seconds is used. CYCLE does
not apply to modifier PS#.
Power supplies set to off toggle the AC
input to the RPSM.
Yes 8. 0
10.0
1
Yes No
QCONFIG Big Picture
Configure
505 =? VC#.IN# QCONFIG=VC2.IN3
QCONFIG:VC2.IN3
Gets / sets Big Picture of wall to specified
sources.
No 2.0 No No
SYSTEM.POWER System Power 1408 =?+- 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
SYSTEM.POWER=ON
SYSTEM.POWER:ON
Toggles system power between on and off. No 1.x Yes Yes
SYSTEM.REBOOT System Reboot 2402 ! SYSTEM.REBOOT
SYSTEM.REBOOT:@ACK
Reboots the system and all system
powered connected components.
No 2.0 Yes Yes
