Planar RPS - Page 13

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 13
020-1332-00I
1
Updated
LOOP.ROUTE.
AUTO
Auto Loop
Routing
113 =? VC# 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
LOOP.ROUTE.AUTO(VC2)?
LOOP.ROUTE.AUTO(VC2):TRUE
Gets / sets the loop out on the specified
video controller will be overridden by zone
setup signal requests.
No 4.0 No No
MASTER.SWITCH Master
Component
Activation
1913 =?+- VC#
PS#
0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=
YES=TRUE
MASTER.SWITCH(VC1)=1
MASTER.SWITCH:TRUE
Gets / sets the specified equipment to be
the master component. Only one
component in an interconnected system
must be set to master or conflicts will
occur. This overrides the physical switch on
the RPS
Yes 2. 0
5.1
1
Yes Yes
MESSAGE.CLEAR System Messages 2325 ! MESSAGE.CLEAR
MESSAGE.CLEAR:@ACK
Clears any system messages from the log Yes 5.1 Yes Yes
PA NEL .AC T IVE.
AUTO
Automatic Panel
Active Area
1521 =? 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
PA NEL .AC T IVE.AUTO ?
PA NEL .AC T IVE.AUTO :YE S
When enabled panel active rects are
computed automatically. Disable to use
PANEL.ACTIVE to override automatic active
area.
No 3.0 No No
PA NEL .P OWE R Panel On/Off 1538 =? PN#
ALL
0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
PANEL.POWER(PN2)?
PANEL.POWER(PN2):0
Gets / sets the specified luminating devices
to on or off
No 7.0
9.0
1
Yes No
PA NEL .S YNC .
ENABLE
Panel Sync
Enabled
1520 =? 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
PANEL.SYNC.ENABLE?
PANEL.SYNC.ENABLE:YES
Gets / sets the scan line inversion for even
row displays (LCD only).
No 2.1 No No
RESET.PANEL Panel Reset 1523 ! 0=ALL
1-999
RESET.PANEL(3)
RESET.PANEL(3):@ACK
Resets connected display equipment to
factory state.
No 3.0 Yes No
VC.AUTO.ENABLE.
ADDRESS
Auto Enable VC =? 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
VC.AUTO.ENABLE.ADDRESS=0
VC.AUTO.ENABLE.ADDRESS:OFF
Gets / sets the auto enabling of VC
addressing to on or off.
No 8.0 Yes Yes
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
