RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 12
020-1332-00I
KEY Remote Key
Codes
1200 =? 0=UP
1=DOWN
2=MENU
9=EXIT
12=LEFT
13=ENTER
14=PREV
15=RIGHT
17=KEY.1
18=KEY.2
19=KEY.3
20=KEY.4
21=KEY.5
22=KEY.6
23=KEY.7
24=KEY.8
25=KEY.9
32=KEY.0
257=STDBY.ENTER
258=STDBY.EXIT
260=TOP
261=PRESETS
262=PRESET1
263=PRESET2
264=PRESET3
265=PRESET4
280=WALL
281=COLOR
282=MISC
283=ARROW.LEFT
284=ARROW.RIGHT
285=STAR.STAR
KEY=262
KEY:262
KEY=STAR.STAR
KEY:STAR.STAR
Refer to OSM section for key definitions:
UP=ARROW UP
DOWN=ARROW DOWN
MENU=MENU TOGGLE
EXIT=EXIT MENU LEVEL
LEFT=ARROW LEFT
ENTER=SELECT
PREV=PREVIOUS MENU
RIGHT=ARROW RIGHT
KEY.1=NUMBER 1
KEY.2=NUMBER 2
KEY.3=NUMBER 3
KEY.4=NUMBER 4
KEY.5=NUMBER 5
KEY.6=NUMBER 6
KEY.7=NUMBER 7
KEY.8=NUMBER 8
KEY.9=NUMBER 9
KEY.0=NUMBER 0
STDBY.ENTER=SYSTEM OFF
STDBY.EXIT=SYSTEM ON
TOP=TOP MENU HIGHLIGHT
PRESETS=OPEN PRESET MENU
PRESET1=SWITCH TO PRESET 1
PRESET2=SWITCH TO PRESET 2
PRESET3=SWITCH TO PRESET 3
PRESET4=SWITCH TO PRESET 4
WALL=OPEN BIG PICTURE MENU
COLOR=OPEN COLOR BALANCE MENU
MISC=OPEN BRIGHTNESS MENU
ARROW.LEFT=CYCLE PANEL # LEFT IN
COLOR BALANCE
ARROW.RIGHT=CYCLE PANEL # RIGHT IN
COLOR BALANCE
STAR.STAR=SELECT ALL PANELS IN COLOR
BALANCE
No 2.0 Yes Yes
LOCAL.DIMMING Enable Local
Dimming
1415 =?+- 0=OFF
1=ON
LOCAL.DIMMING?
LOCAL.DIMMING:OFF
Toggles between local dimming on or off.
Only effective on LCD panels which
support capability.
No 2.0
6.0
1
Yes Yes
LOOP.ROUTE Loop Signal
Output
112 =? VC# 1=IN1
2=IN2
3=IN3
4=IN4
5=DP
LOOP.ROUTE(VC2)=IN3
LOOP.ROUTE(VC2):IN3
Gets / sets the input that will be routed to
the loop out on the specified video
controller.
No 4.0 Yes No
