31
GTEK170R
TECHNICAL
PARTS LIST
FIG-1
1
Clamping feed tube assembly
2
Marker body
3
Quick-release bonnet
4
Bolt assembly
5
Rubber detent
6
Breech sensor (BS) unit
7
Solenoid assembly
8
Rear frame screw
9
Front frame screw
10
Frame assembly
11
Trigger assembly
12
Micro switch
13
SL6 inline regulator assembly
14
Foregrip
15
Battery housing
16
9V battery
17
Push On Purge System (POPS) retaining nut
18
POPS assembly
19
Circuit board (inc OLED board)
20
Navigation console
