PLANET ECLIPSE GTEK170R - Technical; Frame Assembly; Circuit Board Retainer; Breech Sensor Board

FIG-1
40
GTEK170R
TECHNICAL
FRAME ASSEMBLY
FIG-1
1
Navigation console
2
Protective lens
3
LED lightpipe
4
Select push button
5
170R OLED board
6
170R circuit board
7
Micro-switch
8
Micro-switch retaining screws
M2x8 pan cross head
9
170R frame
10
Circuit board retainer
11
Breech sensor board
12
Breech sensor cable
13
Power cable
14
M2.5x5 cap head screw
15
Solenoid retaining pin
9
4
3
8 7 10
11
14
12
1
2
15
5
6
13
