PLANET ECLIPSE GTEK170R - 32 Technical: Tournament Lock Button; Using the Tournament Lock Button

C
B
FIG-2
FIG-1
32
GTEK170R
TECHNICAL
TOURNAMENT LOCK BUTTON
FIG-1
To access the tournament lock button use the 5/64” (2mm) hex key
A
remove the grip screws on the left hand side of the grip
B
.
FIG-2
The tournament lock button
C
is on the left side of the circuit board
(see page 39). To lock / unlock your marker push the button once.
The OLED (or LED) will display the locked / unlocked mode status
(see pages 8-11).
Replace rubber grip and screws as per Fig-1.
1
DO NOT over-tighten the screws.
1
1
B
A
5/64
WARNING!
Always ensure the marker is made safe before changing the tournament lock
state to avoid accidentally ring the marker.
WARNING
+
+
-
-
