FIG-1
37
GTEK170R
TECHNICAL
PUSH ON PURGE SYSTEM (POPS) ASSEMBLY
POPS bonnet
#004 NBR70
Latch spring
POPS button
#004 NBR70
Push rod
#007 NBR70
#005 NBR90
internal o-ring
POPS pin
POPS insert
POPS body
