PLANET ECLIPSE GTEK170R - 170 R Circuit Board; OLED Board

FIG-1
H
E
F
1
G
A
B
C
D
33
GTEK170R
TECHNICAL
170R CIRCUIT BOARD / OLED BOARD
FIG-1 170R circuit board
A
Solenoid valve connector.
B
BS connector.
C
Microswitch connector.
D
Tournament lock button.
E
LED.
F
Select button.
G
OLED board connector.
H
OLED board.
1
IMPORTANT! If you have removed your OLED board
from the main circuit board, be careful when inserting
the pins into the connector to avoid damage to the
pins and/or the boards.
