User’s Manual of GSD-800S / GSD-802S / GSD-802PS
will be forward to the specify port.
• MAC-Address
Specifies the MAC address for which the table is queried.
4.11.2 Static MAC Address
The Static MAC Address page contains a list of static MAC addresses. Static Address can be added and removed from
the page. In addition, several MAC Addresses can be defined for a single port. The screen in Figure 4-48 appears.
Figure-4-48 Static MAC Address Configuration
The configable filelds includes the following items:
• VID
The VLAN ID attached to the MAC Address.
• Ports
Specifies the port numbers for which the table is queried.
• MAC-Address
Input the MAC address entry be manualed bind to the specify port.
The MAC Address Table includes the following fields:
• VID
The VLAN ID attached to the MAC Address.
• Ports
Specifies the port numbers for which the table is queried.
• Type
Static - Static addresses are manually configured. Packets received with the
destinated MAC address mathch the port static MAC setting will be forward to the
specify port.
• MAC-Address
The MAC address listed in the current static address list.
