Planet GSD-802S - Product Specifications

User’s Manual of GSD-800S / GSD-802S / GSD-802PS
z LED easy PoE status Monitoring
z Power feeding on/off and priority configuration
 Management
z Remote Web management interface
z Firmware upgrade through web interface
z Cable Diagnostics technology
z Support SNMPv1 with RFC-1213/1573-Interface group, Ethernet MIB
z SNMP Trap
PRODUCT SPECIFICATION
Model GSD-800S GSD-802S GSD-802PS
Hardware Specification
Copper Ports
8-Port 10/100/1000Base-T Auto MDI/MDI-X
SFP/mini-GBIC slot
- 2 2
PoE Injector Ports
- - 8
Switch architecture
Store-and-Forward
Switch Fabric
16Gbps
Switch throughput
11.9Mpps
Address Table
8K entries
Share data Buffer
176KB On-chip frame buffer
Flow Control
Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex
Dimensions (mm)
( W x D x H )
217 x 135 x 43.5, 1U height
330 x 155 x 43.5,
1U height
Weight
1.1kg 1.2kg 1.8 kg
Power Requirement
100-240V AC, 50-60 Hz
Power Consumption
13.2 Watts maximum,
41.4 BTU/hr
13.2 Watts maximum,
41.4 BTU/hr
130 Watts maximum,
410 BTU/hr
PoE Power Output
- -
48V DC, 15.4W, 350mA
(Ping 1, 2, 3, 6)
Layer 2 Functions
Management Interface
Web Browser, SNMPv1, v2c monitor and SNMP Trap
Port configuration
− Port disable/enable. Auto-negotiation 10/100/1000Mbps full and half duplex
mode selection
− Flow Control disable / enable
− Bandwidth control on each port
VLAN
Port-Based / 802.1Q Tagged Based VLAN, Up to 64 VLAN groups
Link Aggregation
Supports 4 groups of 8-Port trunk, IEEE 802.3ad LACP
QoS
4 Priority Queue and traffic classification based on 802.1p priority, DSCP field
in IP Packet
IGMP Snooping
IGMP (v1/v2) Snooping, up to 64 multicast Groups
Port Mirror
One to many and the monitor mode is RX
SNMP MIBs
RFC-1213 MIB-2
