Page #22 background imageLoading...
Page #22 background image
IP-based 8-port Switched Power Manager with 2 Cascaded Ports
IPM-8221
- 22 -
Chapter 4. Web-based Management
This section provides instructions about how to use the web interface to configure and control the IP
Power Manager remotely.
4.1 Main Page / Home Page
Once you have logged in successfully, the PDU home page will appear as shown below along with the
socket access page:
Figure 4-1-1 Home Page Screenshot
Page Components
Web page components are described as follows:
No.
Item
Description
1
Option Column
This option column contains the main operation categories of THE PDU.
The items that appear in the option column vary according to the user
type. This authorization option is set when the account is established.
2
Alarm Column
Lists the number of alarms related to the PDU running process. You can
click to go to the details page to view the type and content of the alarm
3
Log-in Options
You can perform log-in operations, such as refreshing, logging out,
changing passwords, and querying logs.
4
PDU Operating
Status
Provides real-time information about the device, such as power voltage,
current, power consumption, and temperature/humidity.
