IP-based 8-port Switched Power Manager with 2 Cascaded Ports
IPM-8221
- 23 -
4.1.1 Socket Access
When you log in to the PDU, the user interface will be displayed with the default socket access page
and a menu. The PDU status and socket status contents are displayed on the main block.
Figure 4-1-2 Socket Access Page Screenshot
Only PDUs with this function display the socket status sub-menu block. Other models only
provide PDU status monitoring, which allows you to enable, disable, reset, and schedule
tasks for corresponding port sockets. For detailed descriptions, refer to the subsequent
chapters.
4.1.2 Statistics
You can collect energy consumption statistics based on the specified query time range. Select a start
time from the drop-down list box based on the date, month, and year. You can select energy
consumption within 24 hours, the latest 7 days, 30 days, and 90 days based on the quick selection
function on the time bar.
Figure 4-1-3 Energy Statistics Page Screenshot
The power consumption statistics chart can only display the currently connected PDU.
When the Master PDU is connected to the Slave PDU using the cascade function, only the
Master PDU will be displayed on the statistical web page of the Master PDU. To view the
power consumption statistics of the Slave PDU, you will need to check it on the respective
Slave PDU.
