Gigabit Multi-Homing VPN Security Router User’s Manual
Static Routing will be used. RIP is used when there is more than one router in a network, and if an
administrator doesn’t want to assign a path list one by one to all of the routers, RIP can help refresh the paths.
RIP is a very simple routing protocol, in which Distance Vector is used. Distance Vector determines
transmission distance in accordance with the number of routers, rather than based on actual session speed.
Therefore, sometimes it will select a path through the least number of routers, rather than through the fastest
routers.
Item Description
Working Mode
Select the working mode of the device: NAT mode or Router mode.
RIP
Click “Enabled” to open the RIP function.
Receive RIP
versions
Use Up/Down button to select one of “None， RIPv1， RIPv2，Both RIPv1 and v2” as
the “TX” function for transmitting dynamic RIP.
Transmit RIP
versions
Use Up/Down button to select one of “None，RIPv1， RIPv2-Broadcast，
RIPv2-Multicast” as the “RX” function for receiving dynamic RIP.
82B11.3.2 Static Routing
When there are more than one router and IP subnets, the routing mode for the device should be configured as
static routing. Static routing enables different network nodes to seek necessary paths automatically. It also
enables different network nodes to access each other. Click the button “Show Routing Table” (as in the
figure) to display the current routing list.
- 113 -
