Planet VC-231G User Manual

10
 10/100/1000BASE-T Port for VC-231G and VC-234G
LED Color Function
1000 Green
Lit
Indicates that the port is operating at
1000Mbps.
Blink
Indicates that the VDSL2 Bridge actively
sending or receiving data over that port
at 1000Mbps.
O
Indicates that the port is link down or
10/100Mbps.
100 Green
Lit
Indicates that the port is operating at
100Mbps or 10Mbps.
Blink
Indicates that the VDSL2 Bridge is
actively sending or receiving data over
that port at 100Mbps or 10Mbps.
O
Indicates that the port is link down or
1000Mbps.
 1000BASE-X SFP Port for VC-231GF
LED Color Function
1000 Green
Lit
Indicates that the port is operating at
1000Mbps.
Blink
Indicates that the VDSL2 Bridge actively
sending or receiving data over that port
at 1000Mbps.
O Indicates that the port is link down.

Planet VC-231G Specifications

General

Maximum data transfer rate	1000 Mbit/s
Auto MDI/MDI-X	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Material	Metal
Product type	Network bridge
Product color	Black
Power requirements	DC 5V, 2A
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	184 g
Dimensions (WxDxH)	97 x 70 x 26 mm
