4.5.3 Management VLAN
Configure Management VLAN on this page. The screens in Figure 4-5-1 & Figure 4-5-2 appear.
Figure 4-5-1 Management VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
• Management VLAN
Provide the managed VLAN ID
Buttons
: Click to apply changes.
Figure 4-5-2 Management VLAN State Page Screenshot
The page includes the following fields:
Object Description
• Management VLAN
Display the current management VLAN.
