Planet WGS-4215 Series - Dynamic Address Setting

User’s Manual of WGS Managed Series
240
4.11.2 Dynamic Address Setting
By default, dynamic entries are removed from the MAC table after 300 seconds. The Dynamic Address Setting/Status screens
in Figure 4-11-3 & Figure 4-11-4 appear.
Figure 4-11-3 Dynamic Addresses Setting Page Screenshot
The page includes the following fields:
Object Description
• Aging Time
The time after which a learned entry is discarded
Range: 10-630 seconds;
Default: 300 seconds
Buttons
: Click to apply changes.
Figure 4-11-4 Dynamic Addresses Status Page Screenshot
The page includes the following fields:
Object Description
• Aging Time
Display the current aging time
