Planet WGS-4215 Series - IGMP Querier Setting

User’s Manual of WGS Managed Series
201
4.8.2 IGMP Querier Setting
This page provides IGMP Querier Setting. The IGMP Querier Setting screens in Figure 4-8-8 & Figure 4-8-9 appear.
Figure 4-8-8 IGMP VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID from this drop-down list.
• Querier State
Enable or disable the querier state.
The default value is "Disabled".
• Querier Version
Sets the querier version for compatibility with other devices on the network.
Version: 2 or 3;
Default: 2
Buttons
: Click to apply changes.
Figure 4-8-9 IGMP Querier Status Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID
• Querier State
Display the current querier state
• Querier Status
Display the current querier status
• Querier Version
Display the current querier version
• Querier IP
Display the current querier IP
