User’s Manual of WGS Managed Series
89
Buttons
: Click to add a new view entry.
Figure 4-2-26 SNMP View Table Status Page Screenshot
The page includes the following fields:
Object Description
• View Name
Display the current SNMP view name
• Subtree OID
Display the current SNMP subtree OID
• OID Mask
Display the current SNMP OID mask
• View Type
Display the current SNMP view type
• Action
: Delete the view table entry.
4.2.7.4 SNMP Access Group
Configure SNMPv3 access group on this page. The entry index keys are Group Name, Security Model and Security Level.
The SNMPv3 Access Group Setting screens in Figure 4-2-27 & Figure 4-2-28 appear.
Figure 4-2-27 SNMPv3 Access Group Setting Page Screenshot
The page includes the following fields:
Object Description
• Group Name
A string identifying the group name that this entry should belong to.
The allowed string length is 1 to 16.
• Security Model
Indicates the security model that this entry should belong to.
Possible security models are:
 v1: Reserved for SNMPv1.
 v2c: Reserved for SNMPv2c.
