User’s Manual of WGS Managed Series
Buttons
: Click to add voice VLAN OUI setting.
Figure 4-12-30 Voice VLAN OUI Group Page Screenshot
The page includes the following fields:
Object Description
• OUI Address
Display the current OUI address
• Description
Display the current description
• Modify
Click to edit voice VLAN OUI group parameter
Click to delete voice VLAN OUI group parameter
4.12.6.4 Telephony OUI Port Setting
The Voice VLAN feature enables voice traffic forwarding on the Voice VLAN, then the switch can classify and schedule network
traffic. It is recommended that there be two VLANs on a port - one for voice, one for data. Before connecting the IP device to the
switch, the IP phone should configure the voice VLAN ID correctly. It should be configured through its own GUI. The Telephony
OUI MAC Setting screens in Figure 4-12-31 & Figure 4-12-32 appear.
