User’s Manual of WGS Managed Series
251
The page includes the following fields:
Object Description
• Queue
Select Queue value from this drop-down list
• IP Precedence
Select IP Precedence value from this drop-down list
Buttons
: Click to apply changes.
Figure 4-12-12 IP Precedence Mapping Page Screenshot
The page includes the following fields:
Object Description
• IP Precedence
Display the current CoS value
• Mapping to Queue
Display the current mapping to queue
• Queue
Display the current queue value
• Mapping to IP
Precedence
Display the current mapping to IP Precedence
