Planet WNAP-C3220 User Manual

User Manual of WNAP-C3220
-6-
1.4 Product Specifications
Product
WNAP-C3220
300Mbps 802.11n Wireless Ceiling Mount Range Extender
Hardware Specifications
LAN: 1x 10/100BASE-TX, Auto-MDI/MDIX, 802.3af PoE compliant
Interface
Wireless: IEEE 802.11b/g/n
PoE IEEE 802.3af PoE
Antenna Built-in 3dBi antenna x2
Reset Button
Reset button on rear panel
Press over 7 seconds to reset the device to factory default
LED Indicators PWR/SYS LED x1
Material Plastic
Dimensions (Φ x H) 144 x 33mm
Weight 165g
Power Requirements
Power Supply: DC 12V, 1A
Power over Ethernet: IEEE 802.3af PoE, DC 48V, 0.35A
Power Consumption 11.26W (max.)
Wireless Interface Specifications
Modulation Type
Transmission / Emission Type: DSSS / OFDM
Data modulation type: OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK,
CCK
Frequency Band 2.412~2.484GHz
Operating Channel
America/ FCC: 2.412~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Channel Width 20 or 20/40MHz
Data Rate
IEEE 802.11b: 1/ 2/ 5.5/ 11Mbps
IEEE 802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54Mbps
IEEE 802.11n: 300 Mbps in 40MHz mode / 150Mbps in 20MHz mode
Receiver Sensitivity
IEEE 802.11b: -92dBm @ 1Mbps; -85dBm @ 11Mbps, PER < 8%
IEEE 802.11g: -88dBm @ 6Mbps; -73dBm @ 54Mbps, PER <10%
IEEE 802.11n: -90dBm @ MCS8; -70dBm @ MCS15, PER <10%
RF Power
(Intentional Radiator)
20dBm (max.)
Transmission Distance
Indoor up to 100m
Outdoor up to 300m (it is limited to the environment)
Wireless Management Features
Wireless Modes Access Point, WDS PtP, WDS PtMP, Universal Repeater
Multiple-SSIDs Up to 4
WDS Remote Peers Up to 4

Planet WNAP-C3220 Specifications

General

Brand	Planet
Model	WNAP-C3220
Category	Extender
Language	English
