User Manual of WNAP-C3220
-10-
2.1.2 Hardware Description
LED definition
Object Color State Description
On Power on
Flashing The system is initializing
PWR
Green
Off
LED enabled: Neither Power nor the device is malfunctioned
LED disabled: the device power off or the LED is switched to off
Button definition
Object Description
Reset
Press the Reset button over 7 seconds and then release it. The system restores
to the factory default settings.
H/W Interface definition
Object Description
PoE Port
(802.3af PoE)
10/100Mbps RJ45 port , Auto MDI/ MDI-X
Connect PoE port to the IEEE 802.3af PoE switch to power on the device.
Power Connector
Connect this port to the 12V DC power adapter to power on the device.
