User Manual of WNAP-C3220
-8-
Chapter 2. Hardware Installation
Please follow the instructions below to connect the WNAP-C3220 to the existing network devices and your computers.
2.1 Product Outlook
Dimensions: 144 x 33mm (Φ x H)
Diagram :
Front View – LED Display Side View – Reset Button
Rear View – DC Jack Port Rear View – LAN Port
Figure 2-1 WNAP-C3220 Product Outlook
