16
1. Before installing the media converter into the converter slot
of PLANET media converter chassis, please remove the earth
grounding screw first.
2. Never push the converter into the slot with force; it could
damage the chassis.
3. The Media Converter Chassis supports hot-swap; there is no
need to turn off the whole chassis before sliding in the new
converter.
3.4 Optional DIN-rail Installation
There are two DIN-rail holes on the left side of the XT-715A that allows to
be easily installed by DIN-rail mounting. PLANET optional DIN-rail mounting kit
– RKE-DIN -- can be ordered separately. Refer to the following steps for the
DIN-rail mounting of the XT-715A:
Step 1: Screw the DIN rail on the XT-715A.
Step 2: Now slide the DIN rail into the track.
Step 3: Check whether the DIN rail is tightly on the track.
