12.3.1 Transferring reports to a USB memory stick
Attention!
The functionality of the USB data transfer can only be guaranteed when using the supplied
USB memory stick.
If you use a different USB memory stick, it should match the following specifications to increase the
probability of being compatible:
Capacity: up to 2 resp. 4 GB
File system: FAT
Step Action
1 Selecting the entry "USB"
1.1
Insert the supplied USB memory stick into the USB interface of the electrofusion control unit. If
you want to use a different USB memory stick, make sure it is not write-protected.
1.2
Select the entry "USB" in the function menu, using the ▲- and ▼-buttons.
1.3
Then press the enter button to select the function. The message "Check USB" is displayed for a
short time. The terminal device which is connected to the USB interface is now tested. After that, a
display with the available printing options is shown.
2 The menu "USB"
Display in the "USB" menu.
▲ ▼
Browses through the menu entries
Enter button
Selects the marked entry
Green start button
No function
Red stop button
Abort and return to the main display
2.1
• Make your selection here. You can choose if you want to print all reports or only those that are
stored under a certain job number. Navigate to the desired entry by pressing the ▲- and ▼-
buttons and confirm the selection by pressing the enter button to begin data transfer.
• If you chose to transfer the reports per job number, select the respective job number with the
arrow buttons ▲- and ▼ and confirm your selection with the green start button.
>All (short)
All (long)
Job no. (short)
