11.5.3 During the welding procedure
Step Action
9 During the welding procedure
The display shows the actual and nominal welding time:
Display during the welding procedure
Row 1 shows the actual welding time, which is counted upwards.
Row 2 shows the nominal welding time.
Row 3 shows the specifications of the fitting.
Row 4 shows possible error messages.
11.5.4 After the end of the welding procedure
Step Action
10 End of the welding procedure
The welding process will stop automatically when the actual time reaches the nominal time. This
will be indicated by two bleeps and the following message:
Display after the welding procedure
Row 1 shows the actual welding time, which is counted upwards.
Row 2 shows the nominal welding time.
Row 3 shows the report number under which the weld is stored*.
Row 4 shows date and time of the weld.
11 After the end of the welding procedure
After completion of the welding procedure, the welding terminals can be unplugged cautiously
from the fitting. After that, the display of the device shows the startup message again.
Attention!
• Do not forcefully remove the welding terminals from the fitting.
• Before transporting the electrofusion control unit, unplug the welding terminals from the fitting.
• Observe the cooling time, the processing instructions as well as the processing guidelines o
f
the fitting manufacturer as well as those of the pipe manufacturer.
*) Only with electrofusion control units that have data recording capability.
Nom. time: 30 s
PLA 40 V
Nom. time: 30 s
Report number 3
