14.2 Error messages before and during the welding procedure
Code Error Cause Reaction
E1
Contact error
Invalid SmartFuse©-detection
resistor.
Clean terminals, use another fitting if
possible
E2 Power failure
Last welding was interrupted by
a break of the power supply.
Last welding is faulty! Prepare pipe
again
and use a new fitting!
E3
No contact
No sufficient electrical
contact with the fitting
Check connection to the fitting.
Heating coil or welding cable is
defect
Use another fitting, change welding
cable
E4
Clean SmartFuse tip
Welding contact dirty Check welding terminal resp.clean it
E5
Code error
Faulty input
Move the reading pen over the
barcode in a continuous move with
constant speed.
Barcode defect or
error in code structure
E6
Temperature error
Ambient temperature is out of
limit (-10 to +50 °C)
E7
Temp. meas. error
Temperature measurement is
faulty
Plug in the removable
welding cable. Switch the device off
and on again Welding cable or
sensor defect
E8 Resistance error
Fitting resistance is out of the
range of operation
Use another fitting.
Fitting resistance is out of the
valid working range when using
barcode input
Use another fitting.
E9
Device too hot
Temperature of
transformer is too high
Let the device cool down
for about 45 min
E10 Frequency error
Input frequency out of working
range (40-70 Hz)
Check generator.
E11
Interturn short
circuit
Current increases during
welding by more than 15 %
Short circuit in the heating coil
Welding is faulty!
E12
Input volt. low
Input voltage < 190 V
Fully unwind mains supply cord, use
mains supply cord with suitable
cross section, readjust generator
voltage
E13 Input volt. high
Input voltage > 300 V Adjust generator voltage to 260 V
E14 Peak Error
Peak value of the input voltage
too high
Check generator
