Section 2. Installing the PX-230A Internal ATAPI Drive
PX-230A Installation and Users Manual 31
Audio Connection
Cable
Required
How to Connect It
MPC audio source MPC-
compliant
audio cable
Connect to MPC audio
source, and to analog audio
output connector at the rear
of the Plextor drive.
Sound Blaster or
compatible sound
board
Sound
Blaster-
compatible
analog audio
cable
Connect to Sound Blaster-
compatible audio board and
to analog audio output
connector at the rear of the
Plextor drive.
Digital audio output Cable that’s
compatible
with SPDIF
or Digital-In.
Connect to SPDIF or Digital-
In connector on sound board
(if sound board supports
digital audio) and to digital
audio output connector at the
rear of the Plextor drive.
