Appendix A: PX-230A Specifications
PX-230A Installation and Users Manual 51
Rear Panel (continued)
Analog Audio
Output
Connector
Stereo analog output, Molex connector (L*G*G*R),
MPC-3 standard:
Output voltage (max. volume): 1.5V(p-p)
Load impedance: 10 k ohms
S/N ratio: Min. 75dB
Total harmonic distortion+noise: < 2%
Dynamic range: Typically 75dB (1kHz)
Channel separation: Typically 70dB (1kHz)
Frequency response: 20Hz to 20kHz (0dB ±5dB)
Digital Audio
Output
Connector
Digital audio output for input to SPDIF or Digital-In
input:
Sampling frequency: 44.1 kHz
Output: TTL level, 3.3V
Digital audio line output: 2 pins, non-isolated
Mode Jumper Master (default), slave, cable select (CSEL)
Dimensions and Weight, PX-230A Internal ATAPI Drive
Dimensions
(W/H/D)
(excluding
front panel)
5.75" x 1.63" x 6.8"
146 mm x 41.2 mm x 172.5 mm
Weight 1.8 lbs. (800 g)
